1. C850.1 Phenolic Cotton Laminate (Scrims) (7 yarns, now everyone uses 10 yarns)

Grade: C Canvas Phenolic

Executive standard: GB/T24124-2009

Temperature resistance class: E class

Color: natural color (light yellow or light brown)

Features: High mechanical strength, vertical bending strength and parallel impact strength are higher than other phenolic cotton fabric laminates. Equivalent to NEMA standard C board, similar to IEC standard PFCC201, DIN standard HGW2082 board.

Use: for machinery. Suitable for processing gears, bearings and other mechanical equipment parts.

Thickness: 1.6～50mm

Nominal size: 915×1220mm; 1020×1220mm

2. C850.2 Phenolic Cotton Laminate (Scrims) (12 Yarns)

Grade: CE Canvas Phenolic

Executive standard: GB/T24124-2009

Temperature resistance class: E class

Color: natural color (light yellow or light brown)

Features: Good mechanical and electrical properties, good moisture resistance, equivalent to NEMA standard CE board, similar to IEC standard PFCC202 board, DIN standard HGW2082.5 board.

Uses: electrical. Suitable for processing machinery, electrical equipment insulation structural parts.

Thickness: 1.6～50mm

Nominal size: 915×1220mm; 1020×1220mm

3. C850.3 Phenolic cotton fabric laminate (muslin) (21 yarns)

Grade: Phenolic L Linen

Executive standard: GB/T24124-2009

Temperature resistance class: E class

Color: natural color (light yellow or light brown)

Features: The performance is similar to F850, the machinability is good, and it can be finished. Equivalent to NEMA standard L board, similar to IEC standard PFCC203 board, DIN standard HGW2083 board.

Use: for machinery. It is suitable for processing insulating structural parts of machinery and equipment.

Thickness: 0.6～50mm

Nominal size: 915×1220mm; 1020×1220mm

4. C850.4 Phenolic cotton laminate (muslin) (32 yarns)

Grade: Phenolic LE Linen

Executive standard: GB/T24124-2009

Temperature resistance class: E class

Color: natural color (light yellow or light brown)

Features: high electrical performance, electrical performance is better than C850.2 board; good moisture resistance. Can be finished. Equivalent to NEMA standard LE board, similar to IEC standard PFCC204 board, DIN standard 2083.5 board.

Uses: electrical. Suitable for processing machinery and electrical equipment insulation structural parts.

Thickness: 0.6～50mm

Nominal size: 915×1220mm; 1020×1220mm
