What is G11 epoxy glass fiber tube?

G11 epoxy glass fiber tube is made of glass fiber yarn and resin.This grade is similar to G10/FR4, with the addition of a higher operating temperature and some improved mechanical strength at elevated temperatures. The main difference between NEMA Grades G11 and FR5 is that FR5 is a fire retardant grade of G11.

Glass fiber is usually used as a reinforcing material in composite materials, and is used in electrical insulating materials, thermal insulation materials, circuit substrates and other national economic fields. Glass fiber has continuous grade fiber, fixed-length fiber and distinction, as well as alkali-free, high-alkali and other distinctions.

The diameter of the monofilament ranges from microns to more than 20 microns, which is equivalent to 1/20-1/5 of a hair. There are hundreds of dry monofilament groups in each strand of fiber precursor. It is widely used in various fields of economy, such as reinforced concrete reinforcement materials, electrical insulation materials, thermal insulation materials, circuit substrates, 3D printing technology, development of underground tubes and storage tanks, military, space, armor and sports equipment, etc.

G11 epoxy glass fiber tube can be classified according to different shapes of tubes, such as fiber round tube, fiber square tube, fiber hexagonal tube, fiber special-shaped tube, fiber elbow, etc. This has also resulted in different applications of different tubes and different functions of different tubes. Let's take a detailed look at the various uses of G11 epoxy glass fiber tubes in various fields.

Industrial equipment

There are many applications and types in industrial equipment, such as circular tubes for fiber manipulators, square tubes for fiber gripping arms, fiber rollers and circular tubes for metal parts, etc.

The applications and types in these industrial equipments fully show the advantages of various light weights, making them flexible in application. For example, the fiber drum is light in weight, which can reduce weight, reduce energy consumption and reduce inertia. The fiber manipulator is more convenient to operate and saves energy consumption. At the same time, due to its light weight, there is better control over the accuracy. It also has good fatigue resistance, so it can run for a long time. In addition, it also has the advantage of high temperature resistance, so it can also perform high temperature operation for a long time.

Medical device industry

The medical device industry has very high requirements on the performance and safety of products, and there are many applications in the equipment. For example, fiber shovels and stretchers use fiber round tubes, which are easy to fold and carry. Another example is a fiber wheelchair, which uses a fiber special-shaped tube, which can reduce the weight of the wheelchair, but it has high strength and can fully support the weight of the patient, including high corrosion resistance. Even if it comes into contact with drugs, it can still have good stability.

Sports equipment

In the field of sports and leisure, there will be many products using this material in China, such as fishing rods, but the fiber quality of fishing rods will not be as good as the industrial and medical equipment mentioned above, because the price will be very expensive, so bring G11 Fishing rods with epoxy fiberglass tubing will have more content to determine their value. Another example is the badminton racket, which has very good toughness and grip, which makes the badminton racket more textured, including a better sense of balance. Then golf clubs also have the same application advantages. Including fiber paddles, fiber bicycles, etc. are all made of G11 epoxy fiberglass tubes.

Aerospace

The application of fiber products in the aerospace field is still very extensive. The aerospace industry is one of the industries that the country attaches great importance to, so the selection of materials is also very particular. Because the various properties of the fiber are very in line with the requirements of various indicators in the aerospace field, so. For example, fiber aircraft wings can reduce the overall weight of the aircraft and save a lot of fuel loss, including the huge resistance of the aircraft wings in flight. The high strength brings a very good support effect and ensures safety.

For more informations aboutG-11 Epoxy Tube,Please click here or contact JY Machinery today.
